Pourquoi vous allez l'aimer ?
Une configuration performante pour les pilotes les plus exigeants
Un design aux couleurs emblématiques de la marque, symbole de performance et d'expertise dans les technologies carbone Le nouveau groupe électronique Shimano Ultegra Di2 R8100 12 vitesses pour une fiabilité et une efficacité maximales Roues 100 % carbone LOOK R38D, conçues pour la vitesse
Spécifications techniques
Cadre | LOOK 795 BLADE RS disc |
---|---|
Tige de selle | LOOK AEROPOST 3, length 400 mm. Superlight aero full carbon. Offset 31,8 mm carbon clamp ti screw |
Selle | LOOK by S MARCO SHORT FIT DYNAMIC open fit |
Potence | LOOK ADS (XS 90/S 100 / M – L 110 / XL 120) |
Cintre | LOOK ADH 1.2 CARBON (XS 38 /S 40 / M – L 42 / XL 44) |
Roues | LOOK R 38 D CARBON TUBELESS |
---|---|
Pneus | CONTINENTAL GP 5000 TL TUBELESS 700 x 25 |
Pédalier | SHIMANO ULTEGRA R8100 52 x 36 (XS-S 170/M-L 172,5 /XL 175) |
---|---|
Chaîne | SHIMANO M8100 12 SPEED |
Boîtier de pédalier | BB 386 / Token Ninja 24 mm |
Cassette | SHIMANO ULTEGRA R8100 11 x 34 |
Manettes | SHIMANO ULTEGRA DI2 R8170 |
Dérailleurs | SHIMANO ULTEGRA DI2 R8150 |
Disques | SHIMANO RT MT800 F: 160 mm R : 140 mm |
Tige de selle | LOOK AEROPOST 3, length 400 mm. Superlight aero full carbon. Offset 31,8 mm carbon clamp ti screw |
---|---|
Selle | LOOK by S MARCO SHORT FIT DYNAMIC open fit |
Potence | LOOK ADS (XS 90/S 100 / M – L 110 / XL 120) |
Cintre | LOOK ADH 1.2 CARBON (XS 38 /S 40 / M – L 42 / XL 44) |
Tailles | XS - S - M - L - XL |
---|
Géométrie

795 BLADE RS DISC
Diamètre des roues : 686 mm / 27 inch
XS | S | M | L | XL | |
---|---|---|---|---|---|
Stack | 505 | 529 | 553 | 578 | 601 |
Reach | 367 | 377 | 386 | 396 | 406 |
I - Head tube (°) | 71,8 | 71,8 | 73 | 73 | 73 |
J - Seat tube (°) | 75,8 | 75,8 | 75,8 | 75,8 | 75,8 |
A - Seat tube | 445 | 469.7 | 494.4 | 519.2 | 544 |
B - Top Tube horizontal | 494.1 | 510.1 | 526.2 | 545 | 558.3 |
C - Front Center | 567.7 | 585.5 | 584.3 | 601.5 | 618.8 |
D - Trail | 60.1 | 60.1 | 59.9 | 59.9 | 59.9 |
F - Fork offset | 50 | 50 | 43 | 43 | 43 |
G - Chainstays | 415 | 415 | 415 | 415 | 415 |
K - Head tube | 111.9 | 137.1 | 155.7 | 180.8 | 205.9 |
L - Fork | 368 | 368 | 368 | 368 | 368 |
HAV | 65 | 65 | 65 | 65 | 65 |
Standover | 748 | 771 | 796 | 821 | 844 |
Stack (mm) | 505 |
---|---|
Reach (mm) | 367 |
I - Head tube (°) | 71,8 |
J - Seat tube (°) | 75,8 |
A - Seat tube (mm) | 445 |
B - Top Tube horizontal (mm) | 494.1 |
C - Front Center (mm) | 567.7 |
D - Trail (mm) | 60.1 |
F - Fork offset (mm) | 50 |
G - Chainstays (mm) | 415 |
K - Head tube (mm) | 111.9 |
L - Fork (mm) | 368 |
HAV (mm) | 65 |
Standover (mm) | 748 |
Stack (mm) | 529 |
---|---|
Reach (mm) | 377 |
I - Head tube (°) | 71,8 |
J - Seat tube (°) | 75,8 |
A - Seat tube (mm) | 469.7 |
B - Top Tube horizontal (mm) | 510.1 |
C - Front Center (mm) | 585.5 |
D - Trail (mm) | 60.1 |
F - Fork offset (mm) | 50 |
G - Chainstays (mm) | 415 |
K - Head tube (mm) | 137.1 |
L - Fork (mm) | 368 |
HAV (mm) | 65 |
Standover (mm) | 771 |
Stack (mm) | 553 |
---|---|
Reach (mm) | 386 |
I - Head tube (°) | 73 |
J - Seat tube (°) | 75,8 |
A - Seat tube (mm) | 494.4 |
B - Top Tube horizontal (mm) | 526.2 |
C - Front Center (mm) | 584.3 |
D - Trail (mm) | 59.9 |
F - Fork offset (mm) | 43 |
G - Chainstays (mm) | 415 |
K - Head tube (mm) | 155.7 |
L - Fork (mm) | 368 |
HAV (mm) | 65 |
Standover (mm) | 796 |
Stack (mm) | 578 |
---|---|
Reach (mm) | 396 |
I - Head tube (°) | 73 |
J - Seat tube (°) | 75,8 |
A - Seat tube (mm) | 519.2 |
B - Top Tube horizontal (mm) | 545 |
C - Front Center (mm) | 601.5 |
D - Trail (mm) | 59.9 |
F - Fork offset (mm) | 43 |
G - Chainstays (mm) | 415 |
K - Head tube (mm) | 180.8 |
L - Fork (mm) | 368 |
HAV (mm) | 65 |
Standover (mm) | 821 |
Stack (mm) | 601 |
---|---|
Reach (mm) | 406 |
I - Head tube (°) | 73 |
J - Seat tube (°) | 75,8 |
A - Seat tube (mm) | 544 |
B - Top Tube horizontal (mm) | 558.3 |
C - Front Center (mm) | 618.8 |
D - Trail (mm) | 59.9 |
F - Fork offset (mm) | 43 |
G - Chainstays (mm) | 415 |
K - Head tube (mm) | 205.9 |
L - Fork (mm) | 368 |
HAV (mm) | 65 |
Standover (mm) | 844 |
Autres versions
Vous trouverez ce que vous cherchez
Nos produits sont disponibles en plusieurs versions pour répondre aux besoins de clients passionnés comme vous. Que ce soit pour un choix de couleurs ou de spécifications techniques, naviguez librement pour voir toutes les options qui s'offrent à vous.
Votre cadre est garanti à vie
Enregistrer la garantieDOCUMENTS À TÉLÉCHARGER
Size guide
Nous partageons ces données à titre indicatif. Rapprochez-vous de votre revendeur afin de vous assurer de la taille la plus adaptée à votre morphologie.
Size bike | Cyclist's height | |
---|---|---|
XS | < 166 | |
S | 164 - 173 | |
M | 171 - 180 | |
L | ||
XL | > 185 |
XS | < 166 |
---|---|
S | 164 - 173 |
M | 171 - 180 |
L | |
XL | > 185 |
