795 BLADE RS DISC FULL BLACK GLOSSY MAT
795 BLADE RS DISC FULL BLACK GLOSSY MAT

795 BLADE RS DISC FULL BLACK GLOSSY MAT

SKU | 23328

Couleur Full Black Glossy Mat

€5,500.00

Buy in shop


Have you ever wondered what the famous Batmobile would look like if it were a road bike? The 795 BLADE RS DISC in full black comes very close... Equipped with the ultra-reliable SHIMANO ULTEGRA R 8000, it is the only model in our 795 BLADE RS DISC range to feature a mechanical groupset. Yet you will be blown away by the comfort it offers and the unique reactivity as you accelerate out of bends.
Why you'll love it?

Why you'll love it?

Carbon core, performance, versatility

  • Less is more: deep black brilliance and power
  • Mechanical, reliable, proven SHIMANO ULTEGRA 11 speed groupset
  • No rear brake caliper bridge between the seatstays for unprecented aerodynamics and sober design.
  • Estimated weight of 8,3kg (size M)
All you need to know about 795 BLADE RS

Technical specifications

Made by LOOK
Frame Very high modulus UD carbon finish
Seatpost LOOK AEROPOST 2. carbon 400 mm
Saddle LOOK by San Marco short fit dynamic narrow open fit
Stem LOOK ADS ( XS 90 / S 100 / M-L 110 / XL 120 )
Handlebar LOOK LS2 ALLOY ( XS-S 40 / M-L 42 / XL 44 )
Wheels
Wheels SHIMANO RS 370 Tubeless
Tires Hutchinson fusion 5 Performance 28
Transmission & brakes
Crankset SHIMANO ULTEGRA R 8000 ( XS-S 170 / M-L 172,5 / XL 175 )
Chainrings SHIMANO ULTEGRA R 8000 52 x 36
Chain SHIMANO ULTEGRA HG 601
Bottom bracket BB 386 / Token ninja TF 38624
Cassette SHIMANO ULTEGRA R 8000 11x32
Shifters SHIMANO ULTEGRA
Derailleurs SHIMANO ULTEGRA R 8000
Rotors SHIMANO CENTERLOCK RT 800 F : 160 mm R : 140 mm
Components
Seatpost LOOK AEROPOST 2. carbon 400 mm
Saddle LOOK by San Marco short fit dynamic narrow open fit
Stem LOOK ADS ( XS 90 / S 100 / M-L 110 / XL 120 )
Handlebar LOOK LS2 ALLOY ( XS-S 40 / M-L 42 / XL 44 )
Weight & sizes
Weight 8,33 kgs * (size M / without pedals) * estimate
Sizes XS - S - M - L - XL

Geometry

Geometry 795 BLADE RS DISC FULL BLACK GLOSSY MAT

795 BLADE RS DISC

Wheels diameter : 680 mm / 26,7 inch


XS S M L XL
Stack 505 529 553 578 601
Reach 367 377 386 396 406
I - Head tube (°) 71,8 71,8 73 73 73
J - Seat tube (°) 75,8 75,8 75,8 75,8 75,8
A - Seat tube 445 469.7 494.4 519.2 544
B - Top Tube horizontal 494.1 510.1 526.2 545 558.3
C - Front Center 567.7 585.5 584.3 601.5 618.8
D - Trail 60.1 60.1 59.9 59.9 59.9
F - Fork offset 50 50 43 43 43
G - Chainstays 415 415 415 415 415
K - Head tube 111.9 137.1 155.7 180.8 205.9
L - Fork 368 368 368 368 368
HAV 65 65 65 65 65
Standover 748 771 796 821 844
Stack (mm) 505
Reach (mm) 367
I - Head tube (°) 71,8
J - Seat tube (°) 75,8
A - Seat tube (mm) 445
B - Top Tube horizontal (mm) 494.1
C - Front Center (mm) 567.7
D - Trail (mm) 60.1
F - Fork offset (mm) 50
G - Chainstays (mm) 415
K - Head tube (mm) 111.9
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 748
Stack (mm) 529
Reach (mm) 377
I - Head tube (°) 71,8
J - Seat tube (°) 75,8
A - Seat tube (mm) 469.7
B - Top Tube horizontal (mm) 510.1
C - Front Center (mm) 585.5
D - Trail (mm) 60.1
F - Fork offset (mm) 50
G - Chainstays (mm) 415
K - Head tube (mm) 137.1
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 771
Stack (mm) 553
Reach (mm) 386
I - Head tube (°) 73
J - Seat tube (°) 75,8
A - Seat tube (mm) 494.4
B - Top Tube horizontal (mm) 526.2
C - Front Center (mm) 584.3
D - Trail (mm) 59.9
F - Fork offset (mm) 43
G - Chainstays (mm) 415
K - Head tube (mm) 155.7
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 796
Stack (mm) 578
Reach (mm) 396
I - Head tube (°) 73
J - Seat tube (°) 75,8
A - Seat tube (mm) 519.2
B - Top Tube horizontal (mm) 545
C - Front Center (mm) 601.5
D - Trail (mm) 59.9
F - Fork offset (mm) 43
G - Chainstays (mm) 415
K - Head tube (mm) 180.8
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 821
Stack (mm) 601
Reach (mm) 406
I - Head tube (°) 73
J - Seat tube (°) 75,8
A - Seat tube (mm) 544
B - Top Tube horizontal (mm) 558.3
C - Front Center (mm) 618.8
D - Trail (mm) 59.9
F - Fork offset (mm) 43
G - Chainstays (mm) 415
K - Head tube (mm) 205.9
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 844

Your frame has a lifetime warranty

Register for warranty

Files for downloading

Product Catalogue

Download

Product information

Download

User's guide

Download

Size guide

Please note this is an approximate size guide. Please contact your dealer for a more precise sizing information.

Size bike Cyclist's height
XS < 166
S 164 - 173
M 171 - 180
L 178 - 187
XL > 185
XS < 166
S 164 - 173
M 171 - 180
L 178 - 187
XL > 185
