765 GRAVEL RS GREEN MAT

765-gravel-rs-green-mat

The call of nature is reflected in the green paintwork of this 765 GRAVEL RS. A single SRAM FORCE 1 front chainring is combined with an 11x36 rear cassette for a wide gearing range to take you anywhere you wish to go. The Mavic All Road Disc CL Tubeless wheelset mounted with VITTORIA tires will be your faithful companion on any terrain. Add a multitude of options to fit your bottle cages, and you are ready to ride for hours!

  • Green Mat

Green Mat

$4,500.00

Buy in shop

Why you'll love it?

Discover your new playground

  • SRAM FORCE 1x with 11x36 rear cassette: precise shifting with exceptional versatility
  • Clearance for tires up to 700x40 or 650x2.1
  • Performance-oriented geometry for all day comfort and confident handling when the trail turns technical

Technical specifications

Made by LOOK

Seatpost LOOK LS2 CARBON 27.2 mm x 350 mm
Saddle LOOK by San Marco short fit carbon FX narrow open fit
Stem LOOK LDS ( XS-S 80 / M 90 / L 100 / XL 110 )
Handlebar LOOK ALLOY LS2 GRAVEL 12° FLARE ( XS-S 40 / M-L 42 / XL 44 )

Wheels

Wheels Mavic all road disc CL Tubeless
Tires Vittoria Terreno Dry 700 X 40 Tubeless Ready

Transmission & brakes

Crankset FORCE 1X CARBON 42T ( XS-S 170 mm / M-L 172,5 mm / XL 175 mm )
Chain SRAM PC 1130
Bottom bracket BB 386 / Token ninja SRAM GXP
Cassette SRAM PG 1170 11X36
Shifters SRAM FORCE 1
Derailleurs SRAM FORCE 1 MEDIUM CAGE
Rotors SRAM CENTERLOCK F: 160 mm R : 160 mm

Components

Seatpost LOOK LS2 CARBON 27.2 mm x 350 mm
Saddle LOOK by San Marco short fit carbon FX narrow open fit
Stem LOOK LDS ( XS-S 80 / M 90 / L 100 / XL 110 )
Handlebar LOOK ALLOY LS2 GRAVEL 12° FLARE ( XS-S 40 / M-L 42 / XL 44 )

Weight & sizes

Weight 8,84 kg * (size M / without pedals) * estimate
Sizes XS - S - M - L - XL

Geometry

Géométrie 765 GRAVEL RS GREEN MAT

765 GRAVEL RS

Wheels diameter: 700 mm / 27 inch


XS S M L XL
Stack 530 554 578 602 626
Reach 355 365 375 385 395
I - Head tube (°) 70.3 70.3 70.3 70.3 70.3
J - Seat tube (°) 74 74 73 73 73
A - Seat tube 470 490 510 535 560
B - Top Tube horizontal 507 524 552 569 586.5
C - Front Center 577 595.5 614 632.5 651
D - Trail 72 72 72 72 72
F - Fork offset 50 50 50 50 50
G - Chainstays 420 420 420 420 420
K - Head tube 111.5 137 162.5 188 213.5
L - Fork 395 395 395 395 395
HAV 70 70 70 70 70
Stack (mm) 530
Reach (mm) 355
I - Head tube (°) 70.3
J - Seat tube (°) 74
A - Seat tube (mm) 470
B - Top Tube horizontal (mm) 507
C - Front Center (mm) 577
D - Trail (mm) 72
F - Fork offset (mm) 50
G - Chainstays (mm) 420
K - Head tube (mm) 111.5
L - Fork (mm) 395
HAV (mm) 70
Stack (mm) 554
Reach (mm) 365
I - Head tube (°) 70.3
J - Seat tube (°) 74
A - Seat tube (mm) 490
B - Top Tube horizontal (mm) 524
C - Front Center (mm) 595.5
D - Trail (mm) 72
F - Fork offset (mm) 50
G - Chainstays (mm) 420
K - Head tube (mm) 137
L - Fork (mm) 395
HAV (mm) 70
Stack (mm) 578
Reach (mm) 375
I - Head tube (°) 70.3
J - Seat tube (°) 73
A - Seat tube (mm) 510
B - Top Tube horizontal (mm) 552
C - Front Center (mm) 614
D - Trail (mm) 72
F - Fork offset (mm) 50
G - Chainstays (mm) 420
K - Head tube (mm) 162.5
L - Fork (mm) 395
HAV (mm) 70
Stack (mm) 602
Reach (mm) 385
I - Head tube (°) 70.3
J - Seat tube (°) 73
A - Seat tube (mm) 535
B - Top Tube horizontal (mm) 569
C - Front Center (mm) 632.5
D - Trail (mm) 72
F - Fork offset (mm) 50
G - Chainstays (mm) 420
K - Head tube (mm) 188
L - Fork (mm) 395
HAV (mm) 70
Stack (mm) 626
Reach (mm) 395
I - Head tube (°) 70.3
J - Seat tube (°) 73
A - Seat tube (mm) 560
B - Top Tube horizontal (mm) 586.5
C - Front Center (mm) 651
D - Trail (mm) 72
F - Fork offset (mm) 50
G - Chainstays (mm) 420
K - Head tube (mm) 213.5
L - Fork (mm) 395
HAV (mm) 70

Your frame has a lifetime warranty

Register for warranty

Files for downloading

Product catalogue

Download

Product information

Download

Size guide

Please note this is an approximate size guide. Please contact your dealer for a more precise sizing information.

Size bike Cyclist's height
XS < 166
S 164 - 173
M 171 - 180
L 178 - 187
XL > 185
XS < 166
S 164 - 173
M 171 - 180
L 178 - 187
XL > 185
