795 BLADE RS PROTEAM WHITE GLOSSY

SKU | 23308

Not quite ready for disc brakes? Yet a fan of electronic shifting? We have the answer: the 795 BLADE RS is equipped with a SHIMANO DURA-ACE Di2 groupset for high-precision shifting. It is the lightest model in the aero range and offers an unparalleled stiffness-to-weight ratio thanks to the High Modulus carbon layup. The CORIMA WS BLACK will make quick work of any hill, while the inertia of the 47mm rims will carry you easily on the flats.

  • Proteam White Glossy

Proteam White Glossy

€8,699.00

Buy in shop

Why you'll love it?

Carbon core, performance, versatility

  • It is no coïncidence that most rockets, and this 795 BLADE RS are all white
  • Aerodynamic, down to the last detail: the 3S Design removes the bridge between the seatstays, but increases comfort!
  • Estimated weight of 8,7kg (size M)

Technical specifications

Made by LOOK

Frame Very High Modulus UD Carbon Finish
Seatpost LOOK AEROPOST 2. Carbon 400 mm
Saddle PROLOGO Dimension Tirox
Stem LOOK ADS ( XS 90 / S 100 / M-L 110 / XL 120 )
Handlebar LOOK ADH 2.1 Carbon ( XS 38 / S 40 / M-L 42 / XL 44 )

Wheels

Wheels CORIMA WS BLACK
Tires Vittoria Corsa G+ 700 X 25

Transmission & brakes

Crankset SHIMANO DURA ACE R 9100 ( XS-S 170 / M-L 172,5 / XL 175 )
Chainrings SHIMANO DURA ACE R 9100 52 X 36
Chain SHIMANO DURA ACE HG 901
Bottom bracket BB 386 / Token Ninja TF 38624
Cassette SHIMANO DURA ACE R 9100 11x28
Shifters SHIMANO DURA ACE Di2
Derailleurs SHIMANO DURA ACE Di2

Components

Seatpost LOOK AEROPOST 2. Carbon 400 mm
Saddle PROLOGO Dimension Tirox
Stem LOOK ADS ( XS 90 / S 100 / M-L 110 / XL 120 )
Handlebar LOOK ADH 2.1 Carbon ( XS 38 / S 40 / M-L 42 / XL 44 )

Weight & sizes

Weight 7,42 kg* (Size M / without pedals) *estimate
Sizes XS - S - M - L - XL

Geometry

Géométrie 795 BLADE RS WHITE GLOSSY

795 BLADE RS

Wheels diameter : 680 mm / 26,7 inch


XS S M L XL
Stack 505 529 553 578 601
Reach 367 377 386 396 406
I - Head tube (°) 71,8 71,8 73 73 73
J - Seat tube (°) 75,8 75,8 75,8 75,8 75,8
A - Seat tube 445 469.7 494.4 519.2 544
B - Top Tube horizontal 494.1 510.1 526.2 545 558.3
C - Front Center 567.7 585.5 584.3 601.5 618.8
D - Trail 59.2 59.2 59 59 59
F - Fork offset 50 50 43 43 43
G - Chainstays 405 405 405 405 405
K - Head tube 111.9 137.1 155.7 180.8 205.9
L - Fork 368 368 368 368 368
HAV 65 65 65 65 65
Standover 745 768 793 818 841
Stack (mm) 505
Reach (mm) 367
I - Head tube (°) 71,8
J - Seat tube (°) 75,8
A - Seat tube (mm) 445
B - Top Tube horizontal (mm) 494.1
C - Front Center (mm) 567.7
D - Trail (mm) 59.2
F - Fork offset (mm) 50
G - Chainstays (mm) 405
K - Head tube (mm) 111.9
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 745
Stack (mm) 529
Reach (mm) 377
I - Head tube (°) 71,8
J - Seat tube (°) 75,8
A - Seat tube (mm) 469.7
B - Top Tube horizontal (mm) 510.1
C - Front Center (mm) 585.5
D - Trail (mm) 59.2
F - Fork offset (mm) 50
G - Chainstays (mm) 405
K - Head tube (mm) 137.1
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 768
Stack (mm) 553
Reach (mm) 386
I - Head tube (°) 73
J - Seat tube (°) 75,8
A - Seat tube (mm) 494.4
B - Top Tube horizontal (mm) 526.2
C - Front Center (mm) 584.3
D - Trail (mm) 59
F - Fork offset (mm) 43
G - Chainstays (mm) 405
K - Head tube (mm) 155.7
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 793
Stack (mm) 578
Reach (mm) 396
I - Head tube (°) 73
J - Seat tube (°) 75,8
A - Seat tube (mm) 519.2
B - Top Tube horizontal (mm) 545
C - Front Center (mm) 601.5
D - Trail (mm) 59
F - Fork offset (mm) 43
G - Chainstays (mm) 405
K - Head tube (mm) 180.8
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 818
Stack (mm) 601
Reach (mm) 406
I - Head tube (°) 73
J - Seat tube (°) 75,8
A - Seat tube (mm) 544
B - Top Tube horizontal (mm) 558.3
C - Front Center (mm) 618.8
D - Trail (mm) 59
F - Fork offset (mm) 43
G - Chainstays (mm) 405
K - Head tube (mm) 205.9
L - Fork (mm) 368
HAV (mm) 65
Standover (mm) 841

Your frame has a lifetime warranty

Register for warranty

Files for downloading

Product catalogue

Download

Product information

Download

User's guide

Download

Size guide

Please note this is an approximate size guide. Please contact your dealer for a more precise sizing information.

Size bike Cyclist's height
XS < 166
S 164 - 173
M 171 - 180
L 178 - 187
XL > 185
XS < 166
S 164 - 173
M 171 - 180
L 178 - 187
XL > 185
