765 OPTIMUM+ METALLIC BLUE GLOSSY
SKU | 24364
The sky blue of this 765 OPTIMUM+ Metallic Blue Glossy is set to carry you to new horizons… Horizons that are synonymous with comfort and simplicity thanks to the endurance-oriented frame geometry and reliable SHIMANO derailleurs, disc brakes and 105 groupset.
€3,199.00
Buy in shop
WHY YOU'LL LOVE IT?
- Say yes to versatility and enjoy the comfort and wide clearance of the 3D Wave seatstays, allowing you to mount tire widths up to 700x42
- An endurance-oriented geometry for ultimate comfort, thanks to a frame 10mm shorter and 20mm higher than a pure racing frame
- Uncomplicated does not mean mundane: the brilliant blue metallic paintwork is sure to stand out in the crowd
Technical specifications
Made by LOOK
| Seatpost | LOOK LS3 Alloy 27,2x350 mm |
|---|---|
| Saddle | San Marco Monza full fit |
| Stem | LOOK LS2 alloy (XS 90 mm / S 100 mm / M-L 110 mm / XL 120mm) |
| Handlebar | LOOK LS2 alloy (XS-S 40 cm/ M-L 42 cm / XL 44 cm) |
WHEELS
| Wheels | Shimano WH RS 171 |
|---|---|
| Tires | Hutchinson Fusion 5 tubeless ready 700x30 mm (bike delivered with inner tube) |
Transmission & brakes
| Crankset | Shimano RS510 (XS-S 170 mm / M-L 172,5 mm / XL 175mm) |
|---|---|
| Chainrings | Shimano RS510 50x34 t |
| Chain | Shimano 105 HG 601 |
| Bottom bracket | BB PF 30 / Token ninja TF 841 - 46 |
| Cassette | Shimano 105 R 7000 11X32 t |
| Shifters | Shimano 105 |
| Derailleurs | Shimano 105 R 7000 |
| Rotors | Shimano centerlock RT 70 Front: 160 mm / Rear: 140 mm |
components
| Seatpost | LOOK LS3 Alloy 27,2x350 mm |
|---|---|
| Saddle | San Marco Monza full fit |
| Stem | LOOK LS2 alloy (XS 90 mm / S 100 mm / M-L 110 mm / XL 120mm) |
| Handlebar | LOOK LS2 alloy (XS-S 40 cm/ M-L 42 cm / XL 44 cm) |
WEIGHT & SIZES
| Weight | 9,4 kg* (size M / without pedals) *estimate |
|---|---|
| Sizes | XS - S - M - L - XL |
Geometry
765 OPTIMUM+
Wheels diameter : 700 mm / 27,6 inch
| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Stack | 530 | 554 | 578 | 602 | 626 |
| Reach | 355 | 365 | 375 | 385 | 395 |
| I - Head tube (°) | 70.3 | 70.3 | 70.3 | 70.3 | 70.3 |
| J - Seat tube (°) | 74 | 74 | 73 | 73 | 73 |
| A - Seat tube | 470 | 490 | 510 | 535 | 560 |
| B - Top Tube horizontal | 507 | 524 | 552 | 569 | 586.5 |
| C - Front Center | 577 | 595.5 | 614 | 632.5 | 651 |
| D - Trail | 70.5 | 70.5 | 70.5 | 70.5 | 70.5 |
| F - Fork offset | 50 | 50 | 50 | 50 | 50 |
| G - Chainstays | 420 | 420 | 420 | 420 | 420 |
| K - Head tube | 111.5 | 137 | 162.5 | 188 | 213.5 |
| L - Fork | 395 | 395 | 395 | 395 | 395 |
| HAV | 70 | 70 | 70 | 70 | 70 |
| Standover | 740 | 764 | 788 | 812 | 836 |
| Stack (mm) | 530 |
|---|---|
| Reach (mm) | 355 |
| I - Head tube (°) | 70.3 |
| J - Seat tube (°) | 74 |
| A - Seat tube (mm) | 470 |
| B - Top Tube horizontal (mm) | 507 |
| C - Front Center (mm) | 577 |
| D - Trail (mm) | 70.5 |
| F - Fork offset (mm) | 50 |
| G - Chainstays (mm) | 420 |
| K - Head tube (mm) | 111.5 |
| L - Fork (mm) | 395 |
| HAV (mm) | 70 |
| Standover (mm) | 740 |
| Stack (mm) | 554 |
|---|---|
| Reach (mm) | 365 |
| I - Head tube (°) | 70.3 |
| J - Seat tube (°) | 74 |
| A - Seat tube (mm) | 490 |
| B - Top Tube horizontal (mm) | 524 |
| C - Front Center (mm) | 595.5 |
| D - Trail (mm) | 70.5 |
| F - Fork offset (mm) | 50 |
| G - Chainstays (mm) | 420 |
| K - Head tube (mm) | 137 |
| L - Fork (mm) | 395 |
| HAV (mm) | 70 |
| Standover (mm) | 764 |
| Stack (mm) | 578 |
|---|---|
| Reach (mm) | 375 |
| I - Head tube (°) | 70.3 |
| J - Seat tube (°) | 73 |
| A - Seat tube (mm) | 510 |
| B - Top Tube horizontal (mm) | 552 |
| C - Front Center (mm) | 614 |
| D - Trail (mm) | 70.5 |
| F - Fork offset (mm) | 50 |
| G - Chainstays (mm) | 420 |
| K - Head tube (mm) | 162.5 |
| L - Fork (mm) | 395 |
| HAV (mm) | 70 |
| Standover (mm) | 788 |
| Stack (mm) | 602 |
|---|---|
| Reach (mm) | 385 |
| I - Head tube (°) | 70.3 |
| J - Seat tube (°) | 73 |
| A - Seat tube (mm) | 535 |
| B - Top Tube horizontal (mm) | 569 |
| C - Front Center (mm) | 632.5 |
| D - Trail (mm) | 70.5 |
| F - Fork offset (mm) | 50 |
| G - Chainstays (mm) | 420 |
| K - Head tube (mm) | 188 |
| L - Fork (mm) | 395 |
| HAV (mm) | 70 |
| Standover (mm) | 812 |
| Stack (mm) | 626 |
|---|---|
| Reach (mm) | 395 |
| I - Head tube (°) | 70.3 |
| J - Seat tube (°) | 73 |
| A - Seat tube (mm) | 560 |
| B - Top Tube horizontal (mm) | 586.5 |
| C - Front Center (mm) | 651 |
| D - Trail (mm) | 70.5 |
| F - Fork offset (mm) | 50 |
| G - Chainstays (mm) | 420 |
| K - Head tube (mm) | 213.5 |
| L - Fork (mm) | 395 |
| HAV (mm) | 70 |
| Standover (mm) | 836 |
OTHER VERSIONS
YOU'LL FIND WHAT YOU'RE LOOKING FOR
Our products are available in several versions to meet the needs of passionate customers like you. Whether it's for a choice of colors or technical specifications, navigate freely to see all the options available to you.
YOUR FRAME HAS A LIFETIME WARRANTY
Register for warrantyGuida alle taglie
Please note this is an approximate size guide. Please contact your dealer for a more precise sizing information.
| Size bike | Cyclist's height | |
|---|---|---|
| XS | < 166 | |
| S | 164 - 173 | |
| M | 171 - 180 | |
| L | 178 - 187 | |
| XL | > 185 |
| XS | < 166 |
|---|---|
| S | 164 - 173 |
| M | 171 - 180 |
| L | 178 - 187 |
| XL | > 185 |
